A9N61533 Schneider miniature circuit breaker – C60H – 2 poles – 25 A – C curve MCB

Category	Details
Main
Range	Acti 9
Product name	Acti 9 C60H-DC
Product or component type	Miniature circuit-breaker
Device short name	C60H-DC
Device application	Distribution
Poles description	2P
Number of protected poles	2
[In] rated current	25 A at 25 °C
Network type	DC
Trip unit technology	Thermal-magnetic
Curve code	C
Breaking capacity	10 kA Icu at 440 V DC (EN/IEC 60947-2) 6 kA Icu at 500 V DC (EN/IEC 60947-2) 20 kA Icu at 220/250 V DC (GB 14048.2 / IEC 60947-2)
Utilisation category	Category A (EN/IEC 60947-2)
Suitability for isolation	Yes (EN/IEC 60947-2)
Standards	EN 60947-2, IEC 60947-2
Disclaimer	This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
Date	Aug 1, 2021

Complementary
Network frequency	50/60 Hz
[Ue] rated operational voltage	500 V DC
[Ics] rated service breaking capacity	15 kA 75% at 220/250 V DC (EN/IEC 60947-2) 4.5 kA 75% at 500 V DC (EN/IEC 60947-2) 7.5 kA 75% at 440 V DC (EN/IEC 60947-2)
[Ui] rated insulation voltage	500 V DC (EN/IEC 60947-2)
[Uimp] rated impulse withstand voltage	6 kV (EN/IEC 60947-2)
Contact position indicator	Yes
Control type	Toggle
Local signalling	ON/OFF indication
Mounting mode	Fixed
Mounting support	35 mm symmetrical DIN rail
Comb busbar / distribution block compatibility	Top or bottom: standard
9 mm pitches	4
Net weight	0.256 kg
Colour	White
Mechanical durability	20000 cycles
Electrical durability	3000 cycles at 500 V DC 6000 cycles at 500 V DC
Provision for padlocking	Padlockable
Locking options description	In position O
Tightening torque	Power circuit: 2.5 N·m (top or bottom)
Earth-leakage protection	Without

Environment
Standards	EN 60947-2, IEC 60947-2
Pollution degree	3 (EN/IEC 60947-2)
Overvoltage category	IV
Tropicalisation	2 (IEC 60068-2)
Operating altitude	2000 m
Ambient air temperature (operation)	-25 to 70 °C
Ambient air temperature (storage)	-40 to 85 °C

Offer Sustainability
Sustainable offer status	Green Premium product
REACh Regulation	REACh Declaration
REACh free of SVHC	Yes
EU RoHS Directive	Compliant
EU RoHS Declaration	Yes
Toxic heavy metal free	Yes
Mercury free	Yes
RoHS exemption information	Yes
China RoHS Regulation	China RoHS declaration Pro-active declaration (out of China RoHS legal scope)
Environmental Disclosure	Product Environmental Profile

Contractual Warranty
Warranty	18 months
